31.5" PCAP panel mount touchmonitor
Net price (excl.VAT) €1215,00
Art.No.:
1020153143 Brand:
A1Touch Solution
Type: AOD320-GPCAP-TPMB, 31.5" Panel mount projected capacitive touchscreen monitor, VGA+DVI.
Descriptions: 31.5 inch panelmount monitor with 10pts pcap touchscreen, bezel free with 6mm thick tempered glass and black coated metal case for vandal proof 24/7 use in public spaces.
Unit is in stock
Applications:
|
Television
|
POS system
|
|
Exhibition
|
Education training
|
|
Public query machine
|
Self-service machine
|
|
Surveillance system
|
And more
|
Product Features:
- Bezel free design with 6mm toughened glass surface.
- Front waterproof
- Precise multi-point (10 points) touching.
- Maintenance free.
- Complete metal monitor with strong stability.
- Supporting plug and play for win-7,-8 and -10. (Mac | Linux | Android with driver).
- Unit can be touched with finger, hand gloves or stylus pencil.
- Fast touch response (less than 10 ms).
Specifications:
|
General
|
|
|
Model:
|
AOD320
|
|
Size:
|
31.5" ( 31.5” active area)
|
|
Panel Type:
|
a-Si TFT active matrix
|
|
Backlight:
|
LED
|
|
Display colour:
|
8 bits
|
|
Color:
|
Black
|
|
Material:
|
Metal housing, Glass: 6mm hardened cover glass
|
|
Mounting Option:
|
VESA 200x100 mm
|
|
Video Inputs
|
Inputs: VGA/ DVI
|
|
Dimensions
|
|
|
Outside dimensions frame (wxhxd)
|
769.5 x 464 x 69 mm
|
|
Active area (wxh)
|
700.4 x 394.9 +/-0.2mm
|
|
Display
|
|
|
Native resolution:
|
1920 x 1080 @60HZ
|
|
Ratio:
|
16:9
|
|
Contrast:
|
3000:1
|
|
Brightness:
|
500 cd/m
|
|
Viewing Angle (H/V):
|
178/178
|
|
Response time:
|
<8ms
|
|
Backlight life:
|
50.0000 hrs
|
|
Control:
|
OSD Control (Remote control is option)
|
|
Touchscreen
|
|
|
Touch Technology:
|
Projected capacitive Touch (G+G)
|
|
Detected touches
|
10 touches.
|
|
Response time:
|
<10ms
|
|
Input Method:
|
Finger, hand gloves, or conductive stylus
|
|
Touch times:
|
Unlimited
|
|
Touch Activation Force:
|
No minimum touch activation force is required.
|
|
Controller type:
|
EETI chipset 31xx
|
|
Operating System Support:
|
Windows2000, XP, 7, 8, 10, Android, MAC and Linux.
|
|
Environment
|
|
|
Temperature:
|
Operating: -10°C ~ 70°C
Storage: -20°C ~ 80°C
|
|
Relative Humidity:
|
Operating: 90%(non-condensing at max 40°C)
Storage: 90%(non-condensing at max 40°C)
|
|
Altitude:
|
Up to 3000m
|
|
Electrical
|
|
|
Scan frequency:
|
60Hz
|
|
Operation Voltage:
|
Typical +DC 12V, +/- 10% (24 volt option).
|
|
Power Supply:
|
110-220V AC to 24Volt DC, min. 2A
|
|
Power:
|
39 W
|
|
|
|
|
Packing
|
|
|
Agency Approvals:
|
CE, FCC, RoHS
|
|
Weight net.:
|
16.4 kg
|
|
|
|
Applications:
|
Promotions viewer
|
POS system
|
|
Exhibition
|
Education training
|
|
Public query machine
|
Self-service machine
|
|
Surveillance system
|
And more
|
Our touchscreen monitor standard includes: pcap touchscreen with integrated USB chassis controller + USB-A-A cable 1.8 meter and 220 – 24 Volt Power Supply + VGA/DVI Cable
| Opties: | |
| Touch controller interface: | USB, RS232 met externe voeding of RS232 met interne voeding |
|
Specifications : |
 |
| Installation dimensions : | |
| Mounting instructions : | |
| Driver downloads : |  |
