18.5" (touch) Monitor in 19" Rackmount
Net price (excl.VAT) €438,00
Art.No.:
1020153173 Brand:
A1Touch Solution
Type: A1touch-19RM185; 18.5" powder coated 19 inch rack mount (touch) monitor, VGA+DVI+HDMI.
Description: 18.5 inch monitor in black powder coated 19" rack mount, 6HE, on/off button on left front side, VGA/DVI/HDMI, resolution 1366x768px or FHD 1920x1080(Option), 19" Rack mount touch monitor with or without touchscreen; touchscreen options like resistive, ir or protection glass. Black coated metal case for vandal proof 24/7 use is public spaces.
Unit is not in stock.
| Color panel: | Black powder Coated (other colors on request) |
| Model: | 18.5 inch WXGA TFT LCD Monitor |
| Type: | 18.5 inch-wide Color a-Si TFT-LCD Module |
| Resolution (max): | 1366(x3) x 768 or FHD:1920x1080 (option) |
| Color: | 16,2 million |
| Pixel: | 300 (per one triad) × 300 |
| Brightness: | 250 cd/m² |
| Contrast ratio: | 1000:1 |
| Viewing angle: | 85°/85° horizontal & 80°/80° vertical |
| Response time | 5 ms |
| Active area: | 409.8 (H) x 230.4 (V) |
| VGA input | Analog RGB (D-Sub 15-pins) + DVI + HDMI |
| Plug and play: | Yes DDC1 /DDC2B |
| Power: | 230-100VAC to 12VDC power supply and EU power cable included |
| Power consumption: | <35 watt max. |
| Power consumption stand by: | <4 watt max. |
| Temperature opration mode: | 0 °C - 50 °C |
| Humidity operation mode: | 10% ~ 90% R.H. |
| Size | 483x264x50mm (wxhxd) |
| Weight | 5.4 Kg |
| Mounting: | VESA 100mm |
| Users Mode: | OSD Key: Menu / Select / Power / Down / Up |
| Compatibility: | VESA / IBM / MAC |
| Options: | |
| Functionality: | With or without touch |
| - without touch: | Acrylic or glass |
| - with touch: Type of Touch: |
5 wire resitive, Surface Accoustic Wave or Projected Capacitive Not sure what to use? Call us at +31 (0)45 5748190 or send us contactform |
| - 5 wire resistive : | -Standard non-glare. -Touchable with finger, glove and stylus. -Single touch -activation force less than 40 gramm. |
| - SAW: | -Standard glare. -Touchable with finger and glove. -Single touch -activation force less than 85 gramm. |
| - Projected Capacitive: | -Standard glare. -Touchable with finger, glove and pcap stylus. -10 points touch -activation force less than 1 gramm. |
| External protection: | Standard IP44 or IP65 (not for SAW) |
| Touch controller interface: | USB, RS232 with external power or RS232 with internal power |
| Video input: | VGA+DVI+HDMI |
|
Specifications / Manual : |
 |
| Dimensions : | |
| Driver downloads : |  |
You can purchase by selecting below mentioned options (if available). More info on tab "Options")
Next add amount of products and push the button "Add to cart" and follow further on screen instructions. We advise you to make an account during the checkout if you are planning to buy more often.
Discount on prices:
- Resellers/ installers and Manufacturers (OEM) are advised to login or register to receive discount on prices. After login discounted net.price excl.VAT for the product is given.
- For projects with larger amounts than 5 pieces we advise you to contact us by webform or by phone: +31 (0)45 574 81 90.
Available options:
